Bentonite Foundry Grade

Bentonite Foundry Grade
Bentonite Foundry Grade
Send Inquiry
Product Code : 06
Price And Quantity
  • Minimum Order Quantity
  • 25 tons Ton
  • Price Range
  • 45.00 - 75.00 USD ($)
Product Specifications
  • Product Type
  • Bentonite
  • Moisture
  • 12% max
  • Appearance
  • Powder
Product Description

From our extensive spectrum of bentonite products, we are engaged in providing supreme range of Bentonite Foundry Grade. This bentonite is widely used as bonding material in foundry, sand castings and mouldings. The offered bentonite is processed using the finest grade chemical compounds and cutting-edge techniques by our adroit professionals. It is also used for waterproofing slurry walls. Furthermore, our customers can get this Bentonite Foundry Grade from us at market leading rates.


  • Safe to use
  • Highly effective
  • Excelling binding property
  • High water absorbing capacity

Bentonite Foundry Grade

We are Mfg & exporting Foundry Grade bentonite, Our Specification for Foundry grade Bentonite is displayed below. We are Involved with Activation & Processing,



Our Lab Results

Free Swelling Volume 2 gm/100 ml


30 to 35

Montromonillite content


75% Min

Gel Time 2.5 gm/20 ml



Moisture Content % by Weight


10.00 - 12.00

PH Value 2 % Slurry


8.5 to 9.5

Dry Mesh % Passing 200 B.S.S


85 Minimum

Green Compression Strength


845 to 1265 p/cm2

Green Tensile Strength


>120p / cm2

We offer packaging in 10Kg, 20kg, 25kg, 50kg 1MT and 1.25MT Bags, HDPE/ Pp and also Paper Bags for 25kg.

We also facilitate 3rd party Inspection of Cargo for specific needs,

Application Industries are - Foundry. / Sand Castings / mouldings


Trade Information
  • FOB Port
  • Mundra
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C), Days after Acceptance (DA), Cash in Advance (CID), Cash Against Delivery (CAD)
  • Supply Ability
  • 50 Ton Tons Per Day
  • Delivery Time
  • 50 Tons per Days
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples are available
  • Packaging Details
  • 25kg bags/50kg bags/1000kg bags/1250kg bags
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
